- Custom waveforms up to 65,536 points at 125 MS/s
- Up to 8192 waveform points at 1 GS/s
- Equation mode with up to 32 segments
- Preset waveforms available
- Sine, Gaussian, Exponential Rise, Exponential Fall, Sinc
- Burst and pulsed modes independently triggered
- Load waveforms from file or input as mathematical function
- Pulsed output with more than 250,000 cycles of dead time
- Phase-synchronized output between two channels
- Truly arbitrary waveform generation
Arbitrary Waveform Generator
Moku:Lab''s Arbitrary Waveform Generator can generate custom waveforms with up to 65,536 points at sample rates of up to 1 GSa/s. Waveforms can be loaded from a file, or input as a piece-wise mathematical function with up to 32 segments, enabling you to generate truly arbitrary waveforms. In pulsed mode, waveforms can be output with more than 250,000 cycles of dead time between pulses, allowing you to excite your system with an arbitrary waveform at regular intervals over extended periods of time.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Option for Preset or Custom Waveforms | Choose between preset waveforms, load points from file or input equation directly |
| Configure Output Phase Synchronization | Phase-synchronized output between two channels |
| Select from Normal or Pulsed Output | Configure pulsed output with up to 250,000 cycles of dead time between pulses |
| Custom Waveforms | Up to 65,536 points at 125 MS/s, and up to 8192 waveform points at 1 GS/s |
| Equation Mode | Up to 32 segments |
| Preset Waveforms | Sine, Gaussian, Exponential Rise, Exponential Fall, Sinc |
| Burst and Pulsed Modes | Independently triggered |
