- Maximum 20 kW output in a 3U size
- Supports a maximum voltage of 1500 V
- Select input voltage from 200 Vac (3-phase) or 400 Vac (3-phase)
- Bleeder ON/OFF function
- Output ON/OFF delay function
- Full-load continuous operation is possible even at ambient temperatures as high as 50 °C (122 °F)
- One-control parallel operation function (up to 25 units of the same model)
- *Please contact us if you wish to operate more than 10 units in parallel
- Touch panel for intuitive operation
- LAN, USB, RS232C, external analog control (isolated type) standard
- External control I/O is standard for both NPN and PNP type PLCs
PXT Series
This high-capacity DC power supply is an optimal solution
The PXT Series of high-performance, high-capacity, wide-range DC power supplies offers a maximum rated output of 20 kW in a compact 3U size. In addition to variable internal resistance, bleeder ON/OFF, and output ON/OFF delay functions, the PXT series has various communication interfaces (LAN, USB, and RS232C as standard). It can be used as a standalone device or integrated into testing equipment. Furthermore, the excellent heat dissipation design guarantees an ambient operating temperature of 50°C, making the unit suitable for harsh, high-temperature testing environments. The PXT Series is also highly scalable, and its capacity can be increased to 500 kW in parallel operation (up to 25 units).
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| PXT20K-500 | 0 to 500V / 0 to 120A, 20 kW, Equipped with LAN interface (LXI compliance) |
| PXT20K-1000 | 0 to 1000V / 0 to 60A, 20 kW, Equipped with LAN interface (LXI compliance) |
| PXT20K-1500 | 0 to 1500V / 0 to 30A, 20 kW, Equipped with LAN interface (LXI compliance) |
