- Can measure all AC and DC parameters
- Enables users to save configuration files
- Facilitates swift loading of previously saved configurations
- Can compare measurements with pre-set values
- Output voltage value of +5V, 0, and -5V according to comparison result
- Extensive computation functions
- Display of efficiency, peak factors, and arithmetic operation results
- Average active power display
- Compatible with SUITA PM Viewer PC application software
- Remote control and data transfer through network interface
- Multiple measurement channels
- Wide current range
- High power and precision measurement
- Semi-rack design for test bench applications
- Suitable for automated assembly line testing
- Multi-channel D/A output
- Extensive I/O ports available
SPA3000 Digital Power Meter
3-channel Digital Power Meter
SPA3000 Digital Power Meter has multiple measurement channels and wide current range which can measure voltage, current and power consumption of the measured devices with high power and precision. The semi-rack design makes it suitable for power consumption test bench and automated assembly line testing. In addition, the device is equipped with a multi-channel D/A output and extensive I/O ports, allowing technicians to adopt the solution to the specific application.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Measurement Accuracy | ± (0.1% of reading + 0.05% of range) |
| Voltage Range | 6V - 1000V |
| Current Range | 500mA - 20A |
| Measurement Bandwidth | DC, 0.1Hz - 100kHz |
| Sampling Rate | up to 100kS/s |
| Resolution | 16 bit |
| Channels | 3 |
| Harmonic Measurements | up to 100th order |
| Internal Storage | 4 GB |
| Programming and Interfaces | USB, Ethernet, RS-232, GPIB (optional), D/A output |
