- Multi-channel parallel data acquisition
- Intelligent operational interface
- Supports touch and handwriting input
- Allows users to use stylus or fingertip to draw diagrams and enter text
- Supports on-site printing by connecting printer via LAN port
- Users can access measurement data via computer
- Transmit data using FTP server function
- Features digital certificate management
- Ensures security of network information
- Modularized design for flexible adjustment
- Stores collected data and operational information in memory
- Displays data on LCD screen after operations
- Supports various display modes (trend, number, bar graph, alarm lists)
SDR1000
Data Acquisition (DAQ) System
SDR1000 Data Acquisition (DAQ) System, with its modularized design, offers flexible adjustment and reduces limitations. SDR1000 stores collected data and operational information in its memory based on time and displays them on the LCD screen after operations and simulations. SDR1000 supports various display modes, including trend, number, bar graph, alarm lists, and others.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Frequency Range | 50/60Hz (±2%) |
| Dynamic Range | 120 dB |
| Measurement Range E Field | 0.1 V/m to 100 kV/m |
| Measurement Range H Field | 0.1 A/m to 100 kA/m |
| Weighted Peak | 2013/35/EU, ICNIRP 2010, and ICNIRP 1998 |
| Temperature Range | -23 ± 2°C |
| Weight | 7.85 kg |
| Dimensions | 292.9mm x 263.5mm x 313.4mm |
