- Flexible, adaptable and modular PCB and IC fault finding system
- Apply different electronic test methods for maximum coverage
- Test signals at PCB edge connector or through test clips and DTIs
- Fixtureless in-circuit testing capability
- Modular expansion with 3 external slots available
- Digital, Universal and Matrix switching channels
- Solid foundation in standard configuration
- Cost effective tailored test resources
- Up to 144 dynamic Universal test channels
- Up to 192 Digital test channels
- 5MHz, 10MHz, 15MHz or 25MHz digital test rate options
PinPoint Alpha
Diagnosys PinPoint Alpha: Adaptable and affordable PCB and IC fault finding system
The PinPoint Alpha system is a flexible, adaptable and modular PCB and IC fault finding system, which allows you to apply different electronic test methods to obtain maximum test coverage and fault detection. Test signals can be applied at the PCB edge connector or through test clips and DTIs to perform fixtureless in-circuit testing. The PinPoint Alpha has been designed to provide modular expansion of test resources and has 3 external slots available for Digital, Universal and Matrix switching channels. Providing a solid foundation in the standard configuration it can be tailored to provide the test resources you require in a cost effective manner.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Architecture | Scalable Architecture and Performance |
| Test Safety | Ultra Fast Test Safety |
| Design | Flexible Adaptable and Modular |
| Fault Detection | Outstanding Fault Detection and Identification |
| Functionality | Advanced Functionality |
| Universal Channels | Up to 144 dynamic Universal test channels |
| Digital Channels | Up to 192 Digital test channels |
| Test Rate Options | 5MHz, 10MHz, 15MHz or 25MHz digital test rate options |
