- Frequency Range: 300 MHz to 1 GHz (useable from 200 MHz)
- Transmit & Receive Capabilities emissions/immunity applications
- Individual Calibration Included per ANSI C63.5 with NIST traceability
- Three-year Standard Warranty
ALC-100
Compact Log Periodic Antenna
The ALC-100 is a broadband, linearly polarized Log Periodic Dipole Array (LPDA) Antenna, operating over the frequency range of 200 MHz to 1 GHz; and with excellent efficiency between 300 MHz and 1 GHz. This antenna is a compact version of the AL100, in that the overall length of the antenna has been reduced by over 13 inches, with only a slight compromise in overall performance.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Frequency Range | 300 MHz to 1 GHz (useable from 200 MHz) |
| Polarization | Linear |
| Nominal Impedance | 50 Ohm |
| Power Handling | 50 Watts Continuous |
| Connector | N-type(female) |
| Specifications | FCC, CISPR, EN, ETSI, FAA, Mil-Std, Automotive, etc. |
| Dimensions (L x W x H) | 21.5” x 5.1” x 25.5” [54.6 x 13 x 64.8 cm] |
