CombiLog Hybrid Antenna

The ACL-6000 CombiLog is a broadband, linearly polarized hybrid antenna. Hybrid antennas are, put simply, log periodic antennas with the feed lines modified to include a set of low frequency antenna elements, Additionally, common-mode chokes are typically installed to reduce common-mode currents flowing on the outer conductor of the coaxial feed line/receive cable. By essentially combining a log periodic and biconical antenna, a hybrid antenna can typically cover, at a minimum, the frequency range of the combined antenna types. The ACL-6000 operates from 30 MHz to 6 GHz as a receiving antenna; and from 80 MHz to 6 GHz as a transmitting antenna.
