- Frequency Range: 25 MHz to 300 MHz
- Complies with ±1 dB Antenna Symmetry/Balance
- Requirements of ANSI C63.5 and CISPR 16-1-4
- Transmit & Receive Capabilities
- Available with Fixed or Collapsible Elements
- Individual Calibration Included
- Three-year Standard Warranty
AB-300M
Broadband, linearly polarized Biconical Dipole Antenna
The AB-300M is a broadband, linearly polarized Biconical Dipole Antenna, operating over the frequency range of 25 MHz to 300 MHz. It can be used as either a receiving antenna (for EMI measurements) or as a transmitting antenna (for immunity tests) at power levels up to 50watts.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Product Name | Biconical Antenna |
| Frequency Range | 25 MHz to 300 MHz |
| Polarization | Linear |
| Ant. Symmetry (balance) | < 1 dB |
| Nominal Impedance | 50Ω |
| Power Handling | 50 Watts (continuous) |
| Connector | N-type (female) |
| Antenna Factors | (Please see the graph on the Chart tab) |
| Isotropic Gain | (Please see the graph on the Chart tab) |
| VSWR/Return Loss | (Please see the graph on the Chart tab) |
| Max. Radiated Field | (Please see the graph on the Chart tab) |
| Test Specifications | FCC, CISPR, EN, ETSI, FAA, MIL-STD 461, Automotive and similar |
| Dimensions | 51.5” x 20.2” x 28.5” [130.8 x 51.3 x 72.4 cm] |
| Weight | 4.5 lbs. [2 kg] |
