- 18–40 GHz broadband frequency
- Built-in low-noise preamplifier
- Low antenna factor for accuracy
- For emissions & immunity tests
- ANSI C63.5 NIST-traceable calibration
- External port for filters/pads
- Flat antenna factor response
- 1100 V/m field with 200W input
- Rugged build for lab or field
- Preamp bypass for high signals
AHA-840
Active Horn Antenna With a broadband, high-gain, low noise preamplifier
The AHA-840 Active Horn Antenna is part of Com-Power’s extensive line of EMC test antennas. The AHA-840 smartly incorporates a broadband, double ridged waveguide horn antenna with precision waveguide to coaxial adapter (meticulously tuned as a set for optimum VSWR performance and impedance matching) and a broadband, high-gain, lownoise preamplifier; integrated into a single, well-built, durable, custom designed assembly which facilitates the flexibility to be configured for almost any application.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Frequency Range | 18 GHz to 40 GHz |
| Polarization | Linear |
| VSWR - Antenna Port | 1.4:1 average (see graph below) |
| P(out) @ 1 dB Compression | >10 dBm |
| Noise Figure | < 6 dB |
| Active Antenna Gain | > 55 dBi |
| Preamplifier Gain | 37 to 43 dB (see graph below) |
| Dimensions | 10.2” x 8.5” x 5.9” (26 cm x 21.7 cm x 15 cm) |
| Weight | 1.5 lbs (0.68 kg) |
| Connector Types | 50Ω [2.92mm] “K type” female (for all RF connections) |
