- Table diameter: 4 feet / 1.2 meters
- Rugged, stable construction excellent for indoor & outdoor use
- Load capacity of up to 1100 lbs / 500 kgs
- Automated control
TTW-400A
4 Feet Automated Turntables for EMC Testing
Com-Power model TTW-400A is a fully automated turntable which can be controlled through the Com-Power AMTTC-300 controller. The turntable is constructed from non-reflective wood material. It also has capability of manual control via toggle switch on the table’s motor box.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Table diameter | 4 feet / 1.2 meters |
| Load Capacity | 1100 lbs / 500 kgs (distributed) |
| Nominal Table Height | 9 inches / 22.8 cm |
| Speed Control | 3 user settable speed settings (via AMTTC-300) |
| Controller Interface | Fiber Optic via Duplex VL (Avago duplex latching POF |
| Input Power | 100 – 240 Vac, 50 Hz / 60Hz (480 VA Max.) |
| Operating Temperature | 40°F to 104°F (5°C to 40°C) |
