TTW-400

4 Feet Manually Operated Turntables

TTW-400 Motorized Turntable is a low-profile, above-ground turntable designed for commercial EMC testing. It supports desktop or floor-standing EUTs and enables smooth clockwise or counterclockwise rotation to identify maximum EMI radiation angles. Equipped with a motorized gear drive and remote control, the TTW-400 also offers optional ramps for easy loading of heavy equipment.

Features

Key capabilities and advantages

▼

Motorized turntable designed for EMC testing
Low-profile, above-ground circular platform
Supports both desktop and floor-standing EUTs
Clockwise and counterclockwise rotation
Remote switch operation
Motor and gear reduction drive for smooth, stable rotation
Optional loading ramp for handling heavy equipment

Specification

Technical specifications and parameters

▼

Table Diameter	4 feet (1.2 meters)
Table Height	9 inches (23 cm)
Load Rating	1000 lbs. (455 kg)
Turntable RPM	2.1
Power	115 VAC, 60 Hz
Remote Switch	Reversing Drum
Extension Cable	9.8 feet ( 3 meters)
Table Weight	149 lb (68 kg)
