- High Gain - 40 dB (Typical)
- Flat Response ±2.5 dB
- Low Noise Figure - 3 dB max
- Pout @ 1 dB Gain Compression - +12 dBm
- Battery Powered
PAM-118A
Wideband 40 dB Gain Preamplifier: 500 MHz - 18 GHz
TThe PAM-118A is a wideband, high gain, bench top microwave preamplifier. The PAM-118A has a frequency range of 500 MHz to 18 GHz. This preamplifier is primarily intended for EMC applications; However, it may be used for other applications that require low noise and high signal amplification.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Frequency | 500 MHz to 18 GHz |
| Gain | 40 dB (Typical) |
| Gain Flatness | ± 2.5 dB |
| RF Input/output | 50 Ω Precision N- type female |
| VSWR ( Input/Output) | 2.2:1 (max) |
| Noise Figure | <3 dB @ 25°C |
| Pout @ 1dB comp | +12 dBm (min) |
| Reverse isolation | 40 dB (typical) |
| Battery Pack | 6 Vdc, 2Ah NimH (rechargeable) |
| DC Power supply | +15Vdc, 500 mA |
| Size | 7.7 x 6.5 x 3.2 inches (184 x 156 x 77 mm) |
| Weight | 2.5 lbs. (1.1Kg) |
