- Broadband - 100 Hz - 30 MHz
- High Gain: 28 dB
- Flat Response: ± 2 dB
- Individual Calibration
- Three Year Warranty
PAL-010
Audio and Low Frequencies Preamplifier
The model PAL-010 are general purpose, broadband, high gain, bench top preamplifi ers. These preamplifi ers reduce fl oor noise and increase system sensitivity to low level signals during Electromagnetic Interference (EMC) testing. They also provide input isolation to your expensive test equipment. The PAL-010 has a frequency range of 100 Hz to 30 MHz.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Frequency | 100 Hz - 30 MHz |
| Application | EMI / EMC Measurements |
| Gain | 28 dB |
| Gain Flatness | ± 2.5 dB |
| Noise Figure | < 1.9 dB |
| Impedance I/O | 50 Ohms |
| Connector Type | BNC (f) |
| Power | 15 VDC, 500 mA |
| Battery Pack | 2 x 6 V NimH Battery packs |
| Size | (L x W x H) 7.5" x 5" x 3" (9 x13 x 7.6 cm) |
| Weight | 3.3 lbs. (1.5 kg) |
