LI-3P-2100

100 Amps Three-Phase Line Impedance Stabilization Network

The LI-3P-2100 consists of four-conductor, 50Ω, 50/250 μH +5Ω Line Impedance Stabilization Networks (LISNs); also known as Artificial Mains V-Networks (V-AMNs). Performance measurements can be conducted using the RLI v2.0 Remote LISN Interface. LISN LI-3P-2100 provides the necessary measurement platform for performing power line conducted emission compliance testing per most worldwide commercial EMI/ EMC requirements, such as FCC (U.S.), CE (Europe), AS/ NZS (Australia/New Zealand), VCCI (Japan), Industry Canada, etc.

Datasheet

Features

Key capabilities and advantages

▼

Frequency range: 9 kHz to 30 MHz
100 A maximum continuous current per line
Fully compliant with CISPR 16-1-2 & ANSI C63.4
50 Ω, 50/250 µH +5 Ω network for 3-phase Delta & Wye systems
Remote or local switching via RLI-100 Remote LISN Interface
Integrated transient limiter with dual 5 dB pads
Air-core inductors for saturation-free performance
Forced-air cooling with two internal cooling fans
50 Ω N-type RF measurement port
Includes connectors and 10 m fiber-optic cable
Three-year standard warranty

Specification

Technical specifications and parameters

▼

Product Type	Three-Phase LISN
Application	Conducted emissions testing
Standards	CISPR 16-1-2, ANSI C63.4
Network Type	50 Ω / 50–250 µH +5 Ω
Frequency Range	9 kHz–30 MHz
9 kHz–150 kHz	<17 to <11 dB
150 kHz–30 MHz	<11 dB
9 kHz–50 kHz	>0 to >40 dB
50 kHz–30 MHz	>40 dB
Maximum Current	100 A continuous per line
AC Voltage	865 V rms (line–line), 500 V rms (L–G)
DC Voltage	600 V DC
RF Port	50 Ω N-Type (female)
Fiber Optic Ports	Avago duplex POF
Remote Power Input	6 VDC, 500 mA
Fan Power Input	15 VDC, 500 mA
Operating Temperature	5–40 °C (40–104 °F)
Cooling	Forced-air, dual internal fans
Weight	184.64 lbs (83.75 kg)
