- Designed for TEMPEST-conducted emissions testing (5 kHz – 1 MHz)
- Provides stable 50Ω impedance for accurate and repeatable results
- Isolates EUT and measurement circuits from power sources to minimize interference
- Compliant with TEMPEST standards for government and military testing
- Supports both AC (270 VAC, 50/60 Hz) and DC (380 VDC) operation
- Handles up to 10 amps of current
- Equipped with a 50 Ω N-type (female) RF measurement connector
- Universal three-pin AC receptacle for EUT connection
- Supplied with NIST-traceable calibration data (ISO-17025 optional)
- Compact, rugged design with a three-year warranty
LIP-120
Tempest Line Impedance Stabilization Network
The LIP-120 Line Impedance Stabilization Network (LISN) is designed specifically for Tempest testing. It provides the necessary measurement platform for performing power line conducted emissions compliance testing.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Frequency Range | 5 kHz to 1 MHz (TEMPEST testing compliant) |
| Impedance | 50Ω |
| Inductance | 1.37 mH |
| Standard Compliance | TEMPEST |
| Number of Lines | 2 (Line & Neutral) |
| Max Current | 10 amps |
| Max Voltage | 270 VAC (50/60 Hz, Line to Ground) / 380 VDC |
| RF Measurement Port | 50Ω, N-type (female) |
| EUT Power Connector | Universal three-pin AC receptacle |
| Dimensions | 11.8 × 8 × 5.1 in (30 × 20.5 × 13 cm) |
| Weight | 9 lb (4.05 kg) |
| Operating Temperature | 5 °C to 40 °C (40 °F to 104 °F) |
| Storage Temperature | –25 °C to +70 °C |
