- Frequency range of 150 kHz to 30 MHz
- 100 Amp AC (forced air cooling)
- Fully compliant with CISPR 16-1-2 / ANSI C63.4
- Air-core inductors to prevent saturation
- Individual calibration included
- Three-year warranty
- Provides defined stable impedance
- Isolates EUT from power source influences
- Accurate and repeatable results
- Suitable for single-phase, dual-phase or DC power systems
LI1100C
150 kHz to 30 MHz CISPR 16-1-2 / ANSI C63.4 50 microhenry / 100 Amps
The LI-1100 Line Impedance Stabilization Network (LISN) provides the necessary measurement platform for performing power line conducted emissions compliance testing as required by most worldwide standards for commercial products. The LI-1100 is compliant with both CISPR 16-1-2 and ANSI C63.4. The LISN provides defined stable impedance and isolates the EUT from power source influences, thereby providing accurate and repeatable results. The LI-1100 includes one pair of, separately housed, single-conductor networks, to be installed in series with each current-carrying conductor in a single-phase, dual-phase or DC power system. A second LI-1100 pair can be used to accommodate 3-phase power systems (Wye or Delta configurations).
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Product Name | Line Impedance Stabilization Network (LISN) |
| Specification | CISPR 16-1-2 / ANSI C63.4 |
| Application | Power Line conducted emission tests |
| Frequency Range | 150 kHz - 30 MHz |
| RF Connector | 50 Ohms N-type (female) |
| Current Rating | 100 Ampere AC, 70 Ampere DC |
| Voltage Rating | 440 VAC (Line to Ground), 620 VDC |
| Inductors | 50 microhenry (air-core) |
| Mains & EUT Connections | Superior Electric SUPERCON shrouded connectors |
| Dimensions (each network) | 10 x 10 x 21 inches / 25.4 x 25.4 x 53.3 cm |
| Weight (each network) | 17 lbs / 7.7 kg |
| Insertion Loss | <0.5 dB (150 kHz - 30 MHz) |
| Isolation | > 40 dB (150 kHz - 30 MHz) |
