- Allows all concentric holes to be drilled simultaneously using a mill
- Intended for use on soft metals such as aluminum or brass
- Also usable on stainless steel at very low feed rates
- Center hole sized to maintain proper characteristic impedance when sliding contacts are NOT used
01-304
This drill and tap set is used to precisely machine the concentric holes needed for mounting V Connectors® in housings.
This is the kit to use when you are NOT using stress relief contacts (also known as sliding contacts).
If you are using V110-1 stress relief contacts to make connections to your microcircuit, order the 01-308 Drill & Tap Set instead.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Model | 01-304 |
| Includes | Drill (Part No. 783-568) and Tap (Part No. 783-569) |
| Usage | For mounting V Connectors without stress relief contacts |
| Material Compatibility | Aluminum, brass, stainless steel (low feed rate) |
| Alternative Kit | 01-308 if stress relief contacts are used |
