- Assures that the cable is properly prepared.
- Eliminates the need to separately measure and mark each cable end.
01-309
The 01-309 is a tool designed to make it easy to correctly cut the ends of the V085 semi-rigid coaxial cable straight, and trim the ends to the proper lengths.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Model | 01-309 |
| Frequency Range | DC to 110 GHz |
| Impedance | 50 Ω |
| Insertion Loss | ~0.70 dB (typical) |
| Return Loss | Better than –16 dB up to 110 GHz |
| Insulation Resistance | >1200 MΩ |
| Contact Resistance (Center Conductor) | ~6 mΩ |
| Power Handling | Up to 6 W (continuous wave) |
