- High-speed wavelength sweeping suitable for industrial optical sensing applications
- Stable output with excellent wavelength repeatability
- Wide tuning range enabling high-resolution spectral and interferometric measurements
- Narrow linewidth for precise sensing performance
- Fast sweep speed ideal for real-time monitoring and dynamic measurements
- High optical output power for long-distance or high-loss sensor environments
- Compact and robust design for factory and industrial environments
- Compatible with fiber-optic sensing systems such as OFDR and swept-source OCT
Wavelength Swept Light Source
Optical Sensing for Industry
A wavelength swept light source emits laser light with a continuously sweeping wavelength. It is suitable for shape measurement and displacement measurement utilizing OFDR (Optical Frequency Domain Reflectometry), an optical sensing method using the coherence of laser light. The OFDR method is also widely known as the FMCW (Frequency Modulated Continuous Wave) method.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Type | Wavelength Swept Light Source |
| Center Wavelength | 1,050 nm / 1,310 nm / 1,550 nm (depending on model) |
| Sweep Range | 50–150 nm |
| Sweep Speed | 20 kHz – 200 kHz (typical) |
| Linewidth | < 0.1 nm |
| Output Power | +5 to +15 dBm |
| Wavelength Accuracy | ±0.1–0.5 nm |
| Coherence Length | > 20 mm (varies by model) |
| Output Interface | Single-mode fiber (SMF) or PM fiber |
| Modulation | Internal or external sweep trigger |
| Operating Temperature | 0°C to 50°C |
| Power Supply | 5 V / 12 V (depending on design) |
| Package Type | Module or benchtop unit |
