- Three-axis isotropic E-field antenna for EMF monitoring
- Wide frequency range from 30 MHz to 3 GHz
- Fast electronic axis scanning for accurate measurements
- Automatic antenna factor download and system integration support
2000-1792-R
Tri-axis E-Field isotropic antenna model 2000-1792-R for EMF measurement system.
Operates from 30 MHz to 3 GHz with integrated RF switch device and microcontroller.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Model | 2000-1792-R Isotropic E-Field Antenna |
| Type | Tri-axis E-field sensor with integrated RF switch and microcontroller |
| Frequency Range | 30 MHz – 3 GHz |
| Typical 3D Isotropy | ≤ ±1.5 dB (300 MHz – 1 GHz), ≤ ±2.3 dB (1 – 3 GHz) |
| Dynamic Range | 0.1 mV/m – 200 V/m (typical) |
| Switching Time | < 10 µs |
