CDN-M425E
CDN-M425E

No image available.

CDN-M425E

150 kHz to 230 MHz

Coupling/Decoupling Network CDN-M425E is with a four conductor power cable. This standard M series CDN has a current rating of 25 Amps. These CDNs cover the frequency range of 150 kHz - 230 MHz. This CDN is recommenced for all power supplies connections. For immunity testing the noisy signals are coupled to each conductor in the supply lines according to EN 61000-4-6 standard.

  • Frequency Range 150 kHz to 230 MHz.
  • Current Ratings of 25, 50 and 100 Amps.
  • Single-Line (M1), Two-Line (M2), Three-Line (M3), Four-Line (M4) and Five-Line (M5) Models.
  • Fully Compliant with CISPR 16-1-2 and IEC 61000-4-6.
  • Three Year Warranty.
  • Product Name: Coupling Decoupling Network (CDN).
  • Compliant Test Standards: IEC / EN 61000-4-6.
  • Application: Four unscreened power cable.
  • Frequency Range: 150 kHz to 230 MHz.
  • RF Input Voltage: 40 V (Max).
  • RF Input Connector: 50 Ω BNC (Female)
  • Voltage Rating: 250 V AC / 350 V DC (Line to Ground).
  • Current Rating: 25 Amps AC / 17 Amps DC (Max).
  • AE and EUT Connections: 4 mm shrouded banana sockets.
  • Common Mode Impedance: 150 kHz - 26 MHz: 150Ω ± 20Ω, 26 MHz - 80 MHz: 150Ω + 60Ω / – 45Ω, 80 MHz - 230 MHz: 150Ω + 60Ω / – 60Ω.
  • Voltage Division Factor: 9.5 dB +4 / -1.
  • Decoupling of Common Mode Disturbance: ≥ 40dB (EUT/AE).
  • Dimensions: 6 x 6 x 13 inches or 15.2 x 15.2 x 33 cm.
  • Weight: 5 lbs. or 2.3 kg.
  • Accessories Available from Com-Power for setting test levels and running the test: AADA-M425E shorting adapters, ADA-515-2 150 Ω to 50 Ω adapters, TEP-050 50 Ω Terminator, ATTN-6-100W Power Attenuator, DCU-300-100W Directional Coupler, ASC series Power Amplifiers.
Chart Image
