- Better than 1 ns resolution.
- Holdover < 1µs/24hr*, < 7µs/week* < 3µs/24hr** < 7µs/24hr*** *temp profile +2C **temp profile within 20C ***temp profile within 40C.
- Aging < 5E-11/mth.
- Accuracy: < 5 x 10E-11 at 25C.
- Warm-up time @ 25C 12 min, 5E-10 4-7 min(a) 25 min(b).
SRO-100 Rubidium Atomic Clock
Low cost GPS/GNSS-disciplined oscillator
The slim SRO-100 is a smart, low cost GPS/GNSS-disciplined oscillator, integrating complex synchronization functionality all in one low-cost, super-small package. It utilizes rubidium frequency standard and the patented SmarTiming+® technology to provide a host of timing features, which were previously implemented externally on a separate circuit board. The SRO intelligently synchronizes, disciplines, and controls any primary reference source, such as GPS/GNSS, Cesium, Hydrogen Maser, and T1/E1, at cutting-edge 1ns resolution.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Size | 101.6×70.61×25.4mm | 4×2.78×1″ |
| Voltage | 24V |
| Tempco | < 1E-10 |
| Input 1PPS | GPS / GNSS |
| Weight | 234 g | 0.51 lbs |
| Input Power | < 7-14W |
| Operating Temp | -20 to 60C |
| Output | 10 MHz |
