- Open TEM cell for EMC pre-compliance testing
- 150mm septum for larger DUTs
- Radiated emissions and immunity testing
- 50Ω stripline geometry
- Wide frequency coverage DC to 3 GHz
- Open structure for convenient DUT placement
- Handles up to 25W RF power
- Prof
TBTC3
Open TEM Cell for EMC Pre-Compliance Testing, 150mm Septum
Open TEM cell for radiated emissions and immunity testing; provides 50Ω stripline geometry for DUT placement.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Length | 1038 mm |
| Width | 501 mm |
| Height | 305 mm |
| Septum Height | 150 mm |
| Frequency Range | DC – 3 GHz |
| Impedance | 50 Ω |
| Maximum RF Power | 25 W |
| VSWR | Low |
