- Dual-Channel High Voltage Linear Amplifiers from 100Vp-p up to 1600Vp-p
- Two amplifiers in one box
- Ultra-linear amplification
- High Bandwidth, up to 1 MHz
- High Slew rate, up to 500V/μ
- Low output impedance, down to 0.1 Ohm
- Wide range of models to suit any performance and/or budget demand
A800DI
Dual Channel HV Amplifier with Phase Inverter
The Pendulum Instruments Dual Channel High Voltage Linear Amplifier A800DI contains two independent A800 amplifiers that share common ground reference and power supply. It features also a low voltage phase inverter that inverts the signal applied to the input of channel 1. The resulting signal can then be connected to the input of channel 2 by means of a short BNC cable (supplied).
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| High Voltage | 1600Vpp 60mA |
| Fixed Gain | 100x |
| Broadband | DC to ca 300kHz |
| Low Output Impedance | <0.1Ω |
| High Slew Rate | 500V/µs |
