- Ultrafast Splicing & Heating
- Lightweight & Compact Design
- Bright Operation Lighting
- Versatile Fiber Holder
- Rapid Response Time
M7+
Compact Active V-Groove Cladding Alignment Fusion Splicer
Stepping forward with the compact elegance of the M+ Series, the M7+ combines advanced features with practical design. With IoT and GPS capabilities, it brings smart connectivity to the forefront. Specializing in cladding alignment, the M7+ ensures fibers are perfectly aligned for consistent splicing results. Its compactness makes it a favorite for on-the-go tasks, but it doesn't compromise on the high-tech features professionals demand. For those seeking a blend of portability with top-tier technology, the M7+ stands out in the fiber optics arena.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Model | M7+ |
| Alignment Method | Active V-Groove Clad Alignment |
| Number of Fibers | Single |
| Applicable Fibers | SM (ITU-T G.652 & G.657) / MM (ITU-T G.651) / DS (ITU-T G.653) / NZDS (ITU-T G.655) |
| Coating Diameter | 100μm – 3mm |
| Cladding Diameter | 80 – 150μm |
| Cleave Length | 5 – 16mm |
| Typical Splice Loss | SM 0.03dB / MM 0.01dB / DS 0.05dB / NZDS 0.05dB / G.657 0.03dB |
| Return Loss | >> 60dB |
| Splice Programs | Max 300 modes |
| Electrode Lifespan | 6000 Arc Discharges |
| Heating Programs | Max 100 modes |
| Heating Time | Quick 9 sec / Average 13 sec (60mm slim sleeve) |
| Protection Sleeve | 20mm – 60mm |
| Data Output | Cloud (View Pro Manager) + USB-C |
| Splice Memory | 20,000 splice data / 10,000 splice images |
| Battery | Capacity 3000mAh / Operation Cycle: 200 cycles (splicing + heating) |
| Power Supply | AC Input 100 – 240V / DC Input 9 – 19V |
| Monitor | 4.3" Color LCD Display, Full Touch Screen |
| Magnification | x320 |
| Size | 124 x 144 x 131 mm |
| Weight | 1.49 kg |
| Pull Test | 1.96 – 2.25 N |
