- SOLA (Smart Optical Link Analyzer)
- 7" touch screen display
- Multiple function modules
- Support one click measurement
- Support PON test
- Portable hand-held OTDR platform
- Multi service applications capability
- Optical power measurement
- Optical fiber end face inspection
- High precision test ability
- Fast response time
- Easy operation
- 35dB dynamic range
- 1000Mbps Ethernet connectivity
- Multiple file format support
A870
Portable Hand-held OTDR
A870 is a portable hand-held OTDR platform, which can realize multi service applications such as optical, optical power, optical fiber end face inspection, etc., and is used for the installation and maintenance of optical cables. It has the characteristics of high precision test ability, fast response time and easy operation.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Display | 7 inches, High Brightness TFT LCD, resolution of 800×480 |
| Distance Unit | m / km / mile / ft / kft |
| Range Settings | km: 0.1, 0.3, 0.5, 1.3, 2.5, 5, 10, 20, 40, 80, 120, 160, 260, 320; mile: 0.06, 0.19, 0.31, 0.81, 1.55, 3.11, 6.21, 12.43, 24.86, 49.71, 74.56, 99.42, 161.6, 198.8 |
| Dynamic Range | SMF: 35dB (1310nm/1550nm/1625nm) |
| Pulse Width | 3ns, 5ns, 10ns, 30ns, 50ns, 100ns, 200ns, 300ns, 500ns, 1us, 2.5us, 5us, 10us, 20us |
| Event Dead Zone | 0.8m |
| Attenuation Dead Zone | 4m |
| Distance Accuracy | ± (1 m + Distance × 2.5 × 10⁻⁵ + Sampling resolution) |
| Linearity | 0.03dB |
| Loss Readout Resolution | 0.001 dB |
| Sampling Points | 256,000 points |
| Refractive Index | 1.000000 – 2.000000 |
| Splitting Ratio | Up to 1:128 splitter |
| File Format | SOR, BMP, JPG, PDF, PON, JPEG, PPX, CGM |
| External Connection | USB2.0, RJ45 (1000Mbps Ethernet) |
| Compatible Connectors | FC / SC / LC |
| Dimension | 275 × 178 × 76 mm (excluding rubber bumper) |
| Weight | 1.72kg (with battery) |
