- High-Frequency Performance: Mode-free, traceable RF transmission up to 65 GHz with low VSWR and insertion loss.
- High Mating Reliability: Gold-plated BeCu center ensures consistent mating over many cycles.
- Assembly with V085 Cable: Designed for V085 termination using tools like Anritsu 01-309 cable fixture and 01-307F soldering tool Scribd.
- Precision Installation: Connector pin depth must be within 0.0 to –0.13 mm relative to the cable jacket face for optimal RF performance.
V101F-R
The V101F-R is RoHS compliant. It contains less than the Maximum Concentration Values (MCVs) for Lead, Mercury, Cadmium, Hexavalent Chromium, PBB and PBDE per EU directive 2002/95/EC.
The following RoHS exemption applies: Lead as an alloying element in copper containing up to 4% (40000PPM) lead by weight.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Model | V101F-R |
| Connectors | V(f) in-line cable connector |
| Excellent Performance | up to 65 GHz |
| Impedance | 50 Ω |
| RoHS Compliance | Yes |
