- Provide stress relief to protect circuits from temperature variations, shock and vibration.
- Provides excellent quality microwave connection to a 0.30 mm pin without the need for soldering.
- Designed to work with K connectors up to 40 GHz.
K110-2-R
K110-2-R is designed to connect to a 0.41 mm or larger, trace on stripline. The installation note for K110-2 shows how to make a connection to stripline.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Model | K110-2-R |
| Application | Stripline stress-relief for circuits with wider stripline traces (≥ 0.41 mm) |
| Frequency Range | DC to 40 GHz, meeting standard K Connector traceable performance |
| Material | Heat-treated beryllium-copper sleeve (~0.025 mm thick), gold-plated over nickel, with bondable tab for connection to stripline trace |
| Mating Durability | Rated for 500+ mating cycles, typical of K Connector components |
| RoHS Compliance | Yes |
