- Excellent Performance up to 40 GHz
- Performance Exceeding SMA Below 18 GHz
- Superior Reliability
- Compatibility with SMA, WSMA, and 3.5 mm
- Complete Testability on Existing Network Analyzers
K103F-R
The K103F-R mates with either the K100 Bead or the K100B Hermetic Bead.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Frequency | DC to 40 GHz |
| Connectors | K(f) flange launcher connector |
| Connector Type | 2.92 mm K-type female (jack) flange launcher |
| Mounting Style | Two-hole flange mount, threaded attachment into housing |
| Impedance | 50 Ω |
| Orientation | Straight flange style |
| Termination Style | Solderless |
| Operating Temperature | –55 °C to +125 °C everything |
| Material | Passivated stainless steel (body) and heat-treated beryllium copper (center conductor) |
| Mating Durability | >500 mating cycles |
| RoHS Compliance | Compliant |
