- Excellent Performance up to 40 GHz.
- Performance Exceeding SMA Below 18 GHz.
- Superior Reliability.
- Compatibility with SMA, WSMA, and 3.5 mm.
- Complete Testability on Existing Network Analyzers.
- RoHS compliant.
K101M-085-R
The K101M-085-R K male in-line cable connector is designed to install on V085 2.16 mm (0.085 inch) semi-rigid cable and provides excellent performance from DC to 40 GHz.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Connector Type | K-type (2.92 mm), male/plug, straight inline cable termination |
| Compatible Cable | V085 semi-rigid coaxial (~2.16 mm / 0.085 in) |
| Frequency Range | DC – 40 GHz |
| Impedance | 50 Ω |
| Return Loss / VSWR | Excellent performance exceeding SMA connectors (typical return loss ≥ 20 dB) |
| Operating Temp | –55 °C to +125 °C |
| Material | Passivated stainless steel body; beryllium copper center plated over nickel |
| Mating Durability | > 500 mating cycles |
| RoHS Compliance | Yes |
