- Accurate reference for SWR measurements.
- Broadband load for instrument and device under test.
28W50
W1 precision metrology-grade terminations for smallest reflections.
Available in male and female (28WF50) configurations for precision loads.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Model | 28W50 |
| Frequency | DC to 110 GHz |
| Test Port Connector | W1(m) |
| Input Impedance | 50Ω |
| SWR | 1.065 to 20 GHz / 1.094 to 65 GHz / 1.329 to 90 GHz / 1.671 to 110 GHz |
| Dimensions | 2.4 x 0.8 |
