- Accurate reference for SWR measurements.
- Precise termination for test instrument or device under test.
V210
The precision, metrology-grade terminations are used in measurement systems that need to achieve the smallest possible reflections.
Their excellent match makes them ideal as a reference for fault location measurements on scalar network analyzers.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Model | V210 |
| Type | Coaxial Termination |
| Frequency Range | DC to 40 GHz |
| Test Port Connector | V(m) |
| Input Impedance | 50Ω |
| SWR | 1.120 to 18 GHz / 1.253 to 26.5 GHz / 1.329 to 40 GHz / 1.432 to 65 GHz |
