- Great for use in the following application:
- Cellular or Wireless
- Tower or in-building
- Production or laboratory
- Operational from DC – 6 GHz
- Robust design for long product life
- Low Insertion Loss
- Exceptional PIM performance across cellular or wireless frequency range
1091-465-R
Adapter, DC to 6 GHz, 4.3-10(f) to N(f), 50 Ohm
Female to female adapter, usable from DC to 6 GHz. Robust design with exceptional PIM performance across cellular or wireless frequency ranges. They support applications in cellular or wireless, tower or in-building as well as production or laboratory measurements using many of the Anritsu handheld instruments.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Model | 1091-465-R |
| Type | RF Adapter (50 Ω) |
| Connector Configuration | 4.3-10 (female) to N-type (female) |
| Frequency Range | DC to 6 GHz |
| Impedance | 50 Ω |
| Insertion Loss | ≤ 0.10 dB (DC–4 GHz), ≤ 0.15 dB (4–6 GHz) |
| Return Loss | ≥ 23 dB (DC–4 GHz), ≥ 21 dB (4–6 GHz) |
