- 2 MHz to 6.0 GHz, N(m), 50 Ohm
ICN50
ICN50 provides improved frequency coverage and accuracy performance. It is compatible with Site Master, LMR Master and Cell Master.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Model | ICN50 (InstaCal™ Calibration Module) |
| Type | Electronic auto-calibration module for Site Master analyzers |
| Frequency Range | 2 MHz to 4.0 GHz |
| Connector | N-type male (N(m)), 50 Ω impedance |
| Compatibility | Works with Site Master models S113C, S114C, S331C, S332C, and Cell Master MT8212A/B |
| Calibration Method | Performs Open-Short-Load (OSL) or FlexCal calibration automatically (~45 seconds) |
| Directivity | ≥ 38 dB for frequencies below 3.5 GHz; ≥ 35 dB up to 4.0 GHz |
