- The 2000-2003-R features a mounting bracket for flexible indoor/outdoor use and a coaxial adapter for easy connection to test instruments.
2000-2003-R
This horn antenna is specifically designed for over-the-air (OTA) and testing measurements for the mmWave commercial communications bands operating in the 5G licensed in 20-40 GHz spectrum. The 2000-2003-R comes as an assembly with a coaxial to waveguide adapter, K(f), as well as a mounting bracket that attaches to any commercial camera or tripod mount. The 2000-2003-R can be used with, but is not limited to, the MS2090A and MS276xA. This antenna is qualified and approved by AT&T and Verizon.
Features
Key capabilities and advantages
Specification
Technical specifications and parameters
| Frequency Response | 24 to 40 GHz. Gain: 17-19 dBi. Return Loss: 14 dB Typical. Beamwidth: 30° Typical. Isolation: 35 dB. Temperature Range: -20°C to +85°C. Connector: 2.92mm K(f). Mount: ¼-20 TPI. Size: 110x40x80mm. |
